Recens® Fully Automatic Bagging Machine

Applications

The Recens® Fully Automatic Bagging Machine is a complete end-of-line packing system that takes empty open-mouth bags from a magazine, opens them, fills each one with a pre-weighed dose of product, and delivers it closed to the take-away conveyor — without an operator touching the bag. Weighing is done net-weight on a servo-driven scale, so every bag is filled to the target weight rather than to a fixed volume. That keeps giveaway under control even when bulk density drifts between batches, and it makes the same machine suitable for flour, feed, fertilizer and granular chemicals.

Key Features

• Fully automatic sequence — bag placing, opening, weighing, filling, compacting, transfer, closing and discharge

• Net-weight filling on a servo-driven scale; accuracy typically within ±0.1 – 0.2 % of target weight

• Two-stage fast / trickle feed, with belt, screw or gravity feeder selected to suit granule or powder

• Handles 15 – 50 kg open-mouth bags: PP woven, PE-laminated woven, kraft paper and PE film

• Automatic bag magazine with vacuum pick-up; a fault-bag ejector clears a mis-picked bag and the machine resumes without stopping the line

• Bag mouth is cleaned and shaped before closing; sewing unit or heat sealer fitted to suit the bag

• Siemens PLC with colour touch-screen HMI — a recipe per bag size and product, recalled in one touch

• Dust-extraction connection, light-curtain guarding and guarded moving parts as standard

Applications

Flour and semolina mills — wheat flour, semolina, bran

Maize, rice and grain mills — maize meal, rice, soymeal

Animal feed plants — compound feed, premix, aqua feed

Fertilizer — urea, NPK and ammonium sulphate, granular or prilled

Chemical and mineral powders — resin, plastic pellets, industrial salts, pigments

Sugar, starch, salt and other free-flowing bulk solids

Technical Specifications

Filling range: 15 – 50 kg per bag (10 kg on request)

Capacity: up to 12 bags per minute (approx. 720 bags/hour), bag weight dependent

Weighing accuracy: ±0.1 – 0.2 % of target weight (net weight, servo scale)

Feeding: two-stage fast / trickle; belt, screw or gravity feeder

Bag types: PP woven, PE-laminated woven, kraft paper and PE film, open mouth

Closing: sewing unit or heat sealer (both available)

Control system: Siemens PLC + colour touch-screen HMI

Power supply: AC 380 V / 50 Hz, approx. 6.5 kW

Compressed air: 0.6 – 0.8 MPa, approx. 0.5 m³/min

Dust extraction: connection provided for a central dust collector

Every line is configured to the project. Send us your bag size, bag weight and required output and we will propose a suitable configuration.

Why Recens

Recens has spent more than two decades engineering bulk material handling and packing equipment for grain, fertilizer, chemical and building-material producers around the world. Every line is built around the customer's own bag, product and layout, then followed through with commissioning supervision and operator training, plus lifetime technical assistance from our own field engineers.
